Product Details:
|
| Power: | 0.15Kw/50Hz | Max Flow: | 56L/min |
|---|---|---|---|
| Max Pressure: | -680mmHg | Warranty: | One Year Warranty |
Product Features:
1. Small size, easy to be installed inside equiment.
2. High efficiency and energy saving.
3. Oil free and environment friendly
4. Low noise. low temperature rise, low vibration
5. Outstanding performance at a reasonable price
6. AC 110 V or 220 V
Application:
* Medical suction device
*Dental vacuum ovens
*Surgical suction unit vauum pump
* Sterilization equipment
* Ear, nose and throat surgery equipment
Specification:
| MODEL | VOLTAGE | FREQUENCY | POWER | AMPERAGE | PRESSURE | FLOW | NOISE | WEIGHT |
| UNIT | V | Hz | Kw | A | mmHg | LVmin | dB | Kg |
| HP-40V | 1Φ | 50 | 0.14 | 1.5 | -680 | 45 | 58 | 6.7 |
| 115V | 60 | 0.12 | 1.1 | -680 | 56 | 58 | ||
| 1Φ | 50 | 0.15 | 0.7 | -680 | 45 | 58 | 6.7 | |
| 220V | 60 | 0.17 | 1.1 | -680 | 56 | 58 |
Applications:
UNIT:mm
| MODEL | A | B | C | D | E | F | G | H | I |
| HP-40V | 148 | 180.5 | 128 | 108 | 195 | 150.75 | Φ7 | 40 | NPT1/4" |
