Product Details:
|
| Power: | 0.45Kw/50Hz | Max Flow: | 205/min |
|---|---|---|---|
| Max Pressure: | -700mmHg | Warranty: | One Year Warranty |
1. Small size, lightweight
2. High efficiency and energy saving.
3. Safety and environment friendly
4. Low noise. low-temperature rise, low vibration
5. Outstanding performance at a reasonable price
6. Security without oil, 100% maintenance-free
7. AC 110 V or 220 V
* Medical suction device, dental equipment
* Various instruments
* Automatic machine assembly
* Vary kinds of machinery.
| MODEL | VOLTAGE | FREQUENCY | POWER | AMPERAGE | PRESSURE | FLOW | NOISE | WEIGHT |
| UNIT | V | Hz | Kw | A | mmHg | L/min | dB | Kg |
| HP-200V | 1Φ | 50 | 0.40 | 4.2 | -700 |
168 |
59 | 8.8 |
| 115V | 60 | 0.48 | 4.4 | -700 | 205 | 59 | ||
| 1Φ | 50 | 0.45 | 2.1 | -700 | 168 | 59 | 8.8 | |
| 220V | 60 | 0.57 | 2.6 | -700 | 205 | 59 |
Applications:
UNIT:mm
| MODEL | A | B | C | D | E | F | G | H | I |
| HP-200V | 148 | 204 | 128 | 108 | 244 | 197.5 | Φ7 | 40 | NPT3/8'' |
