Product Details:
|
| Power: | 0.5Kw/50Hz | Max Flow: | 90L/min |
|---|---|---|---|
| Max Pressure: | 2bar |
1. Small size, lightweight
2. High efficiency and energy saving.
3. Safety and environment friendly
4. Low noise. low-temperature rise, low vibration
5. Outstanding performance at a reasonable price
6. Security without oil, 100% maintenance-free
7. AC 110 V or 220 V
* Medical suction device, dental equipment
* Various instruments
* Automatic machine assembly
* Vary kinds of machinery.
| MODEL | VOLTAGE | FREQUENCY | POWER | AMPERAGE | PRESSURE | FLOW | WEIGHT |
| UNIT | V | Hz | W | A | Bar | L/min | Kg |
| MVP-90C | 115 | 60 | ≤500 | ≤4.5 | 2 | ≥90 | 7.8 |
| SPEED | AMBIENT TEMPERATURE | Noise | PRODUCT DIMENSIONS | MOUNTING DIMENSIONS | |||
| rpm | ℃ | dB | mm | mm | |||
| ≥1680 | 5～40 | ≤67 | 245.5x114x175.5 | 203x88.9 | |||
Applications:
