Product Details:
|
| Power: | 1.1Kw/50Hz | Max Flow: | 172L/min |
|---|---|---|---|
| Max Pressure: | 7bar | Warranty: | One Year Warranty |
Product Features:
1. Small size, lightweight
2. High efficiency and energy saving.
3. Safety and environment friendly
4. Low noise. low-temperature rise, low vibration
5. Outstanding performance at a reasonable price
6. Security without oil, 100% maintenance-free
7. AC 110 V or 220 V
Application:
* Medical suction device, dental equipment
* Various instruments
* Automatic machine assembly
* Vary kinds of machinery.
Specification:
| MODEL | VOLTAGE | FREQUENCY | POWER | AMPERAGE | PRESSURE | FLOW | NOISE | WEIGHT |
| UNIT | V | Hz | Kw | A | Kpa | L/min | dB | Kg |
| HP-200C | 1Φ | 50 | 0.97 | 10.8 | 700 | 148 | 60 | 11.8 |
| 110V | 60 | 1.18 | 10.8 | 700 | 172 | 60 | ||
| 1Φ | 50 | 1.10 | 5.2 | 700 | 148 | 60 | 11.8 | |
| 220V | 60 | 1.15 | 5.5 | 700 | 172 | 60 |
Applications:
UNIT:mm
| MODEL | A | B | C | D | E | F | G | H | I |
| HP-200C | 148 | 204 | 128 | 108 | 274 | 227.5 | Φ7 | 40 | NPT3/8" |
