Product Details:
|
| Power: | 0.34Kw/50Hz | Max Flow: | 90L/min |
|---|---|---|---|
| Max Pressure: | -740mmHg | Warranty: | One Year Warranty |
Product Features:
1. Small size, lightweight
2. High efficiency and energy saving.
3. Safety and environment friendly
4. Low noise. low-temperature rise, low vibration, and smooth operation
5. Outstanding performance at a reasonable price
6. Security without oil, 100% maintenance-free
7. AC 110 V or 220 V
Application:
* Medical suction device, dental equipment
* Various instruments
* Automatic machine assembly
* Vary kinds of machinery.
Specification:
| MODEL | VOLTAGE | FREQUENCY | POWER | AMPERAGE | PRESSURE | FLOW | NOISE | WEIGHT |
| UNIT | V | Hz | Kw | A | mmHg | L/min | dB | Kg |
| HP-120H | 1Φ | 50 | 0.35 | 3.3 | -740 | 79 | 58 | 8.3 |
| 115V | 60 | 0.38 | 3.5 | -740 | 90 | 58 | ||
| 1Φ | 50 | 0.34 | 1.5 | -740 | 79 | 58 | 8.3 | |
| 220V | 60 | 0.41 | 1.9 | -740 | 90 | 58 |
Applications:
| UNIT:mm | |||||||||
| MODEL 型号 |
A | B | C | D | E | F | G | H | I |
| HP-120H | 148 | 182 | 128 | 108 | 244 | 197.5 | Φ7 | 40 | NPT1/4" |
